Highlights

• 8M Series, x8 configuration
• PCIe® (85 ohm) applications
• Signal wire size 31 AWG
• Signal wire size 30 AWG (contact your local 3M sales representative)
• Thinner than other similar AWG twin axial cables
• Thin ribbon cable construction allows easy routing in dense servers
• Extremely tight bend radius facilitates custom foldable ribbon construction enables unique packaging configurations
• Standard lengths of 0.5m, 0.75m and 1.0m
• Custom lengths and folding available
• See 3M.com/SDS for regulatory information

3M™ Multi-Channel I/O Twin Axial Cable Assembly is a family of cable assemblies including; x4 (38p), x8 (74p) connectors utilizing 3M™ Low Loss Twin Axial Cable 85 ohm, 31 AWG which is ideal for PCIe® applications.

3M™ Multi-Channel I/O Twin Axial Cable Assemblies are designed to support high density PCIe(R) applications and meet SFF-TA-1016 specifications. The thin, low profile Twin Ax cable allows for a wider range of routing options and supports extremely tight bend radii for each unique server configuration. Signal Integrity (SI) performance metrics are not degraded, even with multiple folds.
